Description
Indoor&Outdoor Rental LED Display
LED display adopts quick-lock design and supports bending installation, making it easy and fast to install.The cabinet is made of die-cast
aluminum, and all screws and quick locks are made of stainless steel, making it stronger and more durable. It is an ideal rental cabinet.
Indoor 500x500mm Rental LED Display 500 Series Parameter
| Pixel pitch | P1.95 | P2.604 | P2.976 | P3.91 |
| Module size (mm) | 250×250 | 250×250 | 250×250 | 250×250 |
| Module pixels (dots) | 128×128 | 96×96 | 84×84 | 64×64 |
| Scanning mode (S) | 1/32 | 1/32 | 1/28 | 1/16 |
| Physical density (dots) | 262,144 | 147,928 | 112,896 | 65,536 |
| LED packaging | SMD1515 | SMD1515 | SMD2020 | SMD2020 |
| Refresh frequency (Hz) | ≥3,840 | ≥3,840 | ≥3,840 | ≥3,840 |
| White balance (CD/㎡) | 800 | 750 | 800 | 800 |
| Cabinet size (mm) | 500×500 | 500×500 | 500×500 | 500×500 |
| Cabinet pixels (dots) | 256×256 | 192×192 | 168×168 | 128×128 |
| Cabinet weight (Kg) | 6.5 | 6.5 | 6.5 | 6.5 |
| Average power (W) | 160 | 160 | 160 | 192 |
| Maximum power (W) | 480 | 480 | 480 | 576 |
| Viewing distance (°） | 140 | 140 | 140 | 140 |
| The Best View （M） | 2-20 | 3-20 | 3-20 | 4-30 |
| Working voltage （V) | AC100-240V | AC100-240V | AC100-240V | AC100-240V |
| Working temperature (℃） | -20～+60 | -20～+60 | -20～+60 | -20～+60 |
| Protection Grade | IP31 | IP31 | IP31 | IP31 |
Outdoor 500x500mm Rental LED Display 500 Series Parameter
| Pixel pitch | P2.604 | P2.976 | P3.91 | P4.81 |
| Module size (mm) | 250×250 | 250×250 | 250×250 | 250×250 |
| Module pixels (dots) | 96×96 | 84×84 | 64×64 | 52×52 |
| Scanning mode (S) | 1/16 | 1/21 | 1/16 | 1/13 |
| Physical density (dots) | 147,928 | 112,896 | 65,536 | 43,264 |
| LED packaging | SMD1415 | SMD1415 | SMD1921 | SMD1921 |
| Refresh frequency (Hz) | ≥3,840 | ≥3,840 | ≥3,840 | ≥3,840 |
| White balance (CD/㎡) | 4500 | 4500 | 5000 | 4500 |
| Cabinet size (mm) | 500×500 | 500×500 | 500×500 | 500×500 |
| Cabinet pixels (dots) | 192×192 | 168×168 | 128×128 | 128×128 |
| Cabinet weight (Kg) | 7.3 | 7.3 | 7.3 | 7.3 |
| Average power (W) | 240 | 240 | 240 | 190 |
| Maximum power (W) | 720 | 720 | 720 | 560 |
| Viewing distance (°） | 140 | 140 | 140 | 140 |
| The Best View （M） | 3-20 | 3-20 | 4-30 | 4-30 |
| Working voltage （V) | AC100-240V | AC100-240V | AC100-240V | AC100-240V |
| Working temperature (℃） | -20～+60 | -20～+60 | -20～+60 | -20～+60 |
| Protection Grade | IP65 | IP65 | IP65 | IP65 |
Quick Install
Series LED screen two fast Locks on left and top side, ensure faster assembly and better screen flatness.
Corner Protector for LED
Rental LED display is designed with four corner guards to effectively prevent damage to the LED during transportation,
installation, operation and disassembly.
Curved Installation
Rental LED display wall supports curved installation, and can be installed in inner arc or outer arc.
Mixed Splicing
500 and 1000 cabinets can be easily spliced up and down, greatly meeting the different needs of stage design.
IP65 Waterproof
Outdoor series LED display supports IP65 dustproof and waterproof, which can resist harsh weather conditions in outdoor activities.
Excellent Display Experience
3840Hz high refresh rate, high grayscale, and high brightness provide an excellent viewing experienc
Wide Viewing Angle
Viewing angle is up to 140° vertical and horizontal, providing a wide viewing angle.
Ultra-wide viewing angle give you the largest screen viewing area.
Widely Used
Rental LED display is widely used in various scenarios, including event sites, exhibitions,
business meetings, etc. Its flexibility and ease of installation make it ideal for temporary events and long-term use.
