Description
Outdoor Stadium Perimeter LED Board
stadium perimeter LED display features IP65 waterproofing, a rear service design, adjustable brackets, and easy installation. These attributes guarantee efficient operation in diverse stadium environments, delivering an outstanding visual experience to audiences.
Outdoor Stadium Perimeter LED Board
| Pixel pitch | P6.67 | P8 | P10(2s) | P10(4s) |
| Module size (mm) | 320×160 | 320×160 | 320×160 | 320×160 |
| Module pixels (dots) | 48×24 | 40×20 | 32×16 | 32×16 |
| Scanning mode (S) | 1/28 | 1/4 | 1/2 | 1/4 |
| Physical density (dots) | 22500 | 15625 | 10000 | 10000 |
| LED packaging | SMD3535 | SMD3535 | SMD3535 | SMD3535 |
| Refresh frequency (Hz) | 1920 | 1920 | 1920 | 1920 |
| White balance (CD/㎡) | 5500 | 5500 | 5500 | 5000 |
| Cabinet size (mm) | 960×960 | 960×960 | 960×960 | 960×960 |
| Cabinet pixels (dots) | 144×144 | 120×120 | 96×96 | 96×96 |
| Cabinet weight (Kg) | 30 | 30 | 30 | 30 |
| Average power (W) | 300 | 200 | 300 | 200 |
| Maximum power (W) | 800 | 600 | 800 | 600 |
| Viewing distance (°） | 140 | 140 | 140 | 140 |
| The Best View （M） | 6-50 | 8-50 | 10-100 | 10-100 |
| Working voltage （V) | 110/220±10% | 110/220±10% | 110/220±10% | 110/220±10% |
| Working temperature (℃） | -20~+60 | -20~+60 | -20~+60 | -20~+60 |
| Export certification | CCC、CE、ROHS、FCC | CCC、CE、ROHS、FCC | CCC、CE、ROHS、FCC | CCC、CE、ROHS、FCC |
Independent Support Structure
The support structure is meticulously crafted to endure both front and rear impacts while maintaining steadfast stability. The cabinet support angle can be easily adjusted to accommodate the specific on-site conditions.
Impact-resistant Design
LED display is furnished with a soft mask and rubber cover to safeguard athletes from potential injuries during competitions.
Easy to Install
There are two quick locks on the top and left side of the cabinet to support quick installation. Cables between cabinets are connected through cabinet aviation sockets.
Openable Back Cover
LED display boasts a compact structure, and its back cover can be swiftly opened to facilitate maintenance operations.
IP65 Waterproof
With a cabinet rating of up to IP65, the fully sealed cabinet of LED display ensures exceptional weatherproof, dustproof, and damp-proof capabilities, elevating the overall ingress protection to a new standard.
Customized for the Stadium
Stadium perimeter LED display is purposefully crafted for placement around the stadium. Its captivating display effect and expansive field of view enable audiences to immerse themselves in thrilling content.
More Installation Types
LED display screen offers easy installation, allowing for versatile hanging or stacking options. It is well-suited for both fixed and rental applications.
Superb Display Effect
LED display excels in sports commercial display applications. Its elevated brightness and refresh rate deliver users more lifelike and vibrant visual effects.
